Hi Scorpion, thanks for the power supply info, I am relieved that there is only 2 power rails 5 and 12 volts +ve plus ground. I will also need to replace the hard drive, would I be right in thinking that an IDE 40gig unformatted drive would do the job ? Cheers Steve aka Octalplug

Hi There, I am looking for circuit details for the extrenal power supply that is used with the Avtech AVC777 DVR, or the various voltage requirements that need to be connected to the mini DIN socket on the back of the DVR unit. I assume it must at least require 5 and 12 volts plus ground. Cheers Octalplug

Hi Folks, can any one help with technical information on the power supply requirements of the Avtech AVC777 DVR ? Specifically the voltage supply connections to each pin of the 8 pin mini DIN socket on the back panel. A schematic diagram of the external power supply would be very helpful. Cheers Octalplug
