Hi All,
I'm new to security systems (DIY for the home) and I've been trying to research as best I can before asking questions here. Hopefully with what little I know at this point and some help from the group here I can get moving in the right direction. Here's what I'm trying to accomplish, basically a realtively simple CCTV type setup for home security:
1) New house construction, in design phase, so I have flexibility
2) Use of CCTV system is for 'as needed' ability to see what is happening outside the house (most often at night)
3) My initial thought is 16 fixed focal length cameras to cover the perimeter and the ability to scroll through the cameras on a Ethernet / coax capable TV inside the house
4) Wired, not wireless, system
5) Ability to 'turn on' and 'turn off' system as needed (it's an off-grid house, electricity usage is a concern)
6) Not a current need to record images via DVR, but want the ability to add that later if desired
7) Also looking for recommendations for hardware supplier that is decent quality / price point, low maintenance, and not China (US preferred, but from what I'm reading that is a tall order)
I've mocked up the below onto my current house design. The dimensions of the house are listed, and the FOV / viewing distance are relatively to scale against the house dimensions. I assumed the following for now:
1) 2.8mm lens on the cameras
2) 97 degree viewing angle
3) 26ft viewing distance
Please let me know your thoughts on how best to accomplish this type of setup, as well as hardware manufacturers to look at / compare. Thanks!
