tomane1 0 Posted February 9, 2010 Hello. I have a digital recorder dedicated micros D4 but power supply adaptor is missing. At work i have plenty of 5v and 12v adaptors but dont know how to wire it into 8din socket. Please help me with some diagram or picture. Thanks Share this post Link to post Share on other sites
ronbo 0 Posted February 22, 2010 i had this prob before i took unit apart to try to trace it but think i drew a blank sorry not much help Share this post Link to post Share on other sites
barronshark 0 Posted April 30, 2010 on my power supply for a Dedicated micros ds2 there is a sticker (I think the supplys are the same) it shows pins and voltages see attached pic OTHER INFO INPUT 100-200V# 50-60HZ 2.5A OUTPUT +5.0V 6.0A +12.0V 3.0A -12V 0.5A Hope this helps a bit Share this post Link to post Share on other sites
