Problem Getting Zoom Function To Work

[akrh125 0]

I need some help with a PV-300HI camera that I bought recently and am having some trouble with.

The issue that I am having is with the zoom function through my Gadspot DVR. Before attempting to actually install the camera in its planned location, I tested it in the room where the DVR is located. I used a short 6ft CAT5E cable to connect the Red & Black wires on the camera to the TX+/TX- connectors on the back of the DVR. This seemed to work fine and I was able to control the zoom and focus through the DVR.

I then tried to connect it using the 150 ft CAT5E cable that is going to be used for the real installation. I put an RJ45 connector on the Black & Red wires at the camera and then used an RJ45 coupler to connect the camera to the 150 ft CAT5E cable. I was no longer able to get the zoom and focus features to work through the DVR.

I then removed the 150 ft cable and the RJ45 connector and connected the Red & Black wires from the camera directly into the back of the DVR (no CAT5 cables at all). I still cannot get the zoom and focus features to operate at all.



I am at a loss as to what to do now. Any recommendations or help would be greatly appreciated.

[morem_uk 0]

does it still work with the 6ft cable? make sure the cable is connected correctly, i.e Tx+ from DVr connected to Rx+ on the Camera and TX- to Rx-



check if any settings have been changed on the dvr eg: protocol.



hope this helps
