Dedicated micros HELP from experts needed.

[steve w 0]

Hi, I hope someone here can help me, this is a very specific request. I have a KBS3 controller from dedicated micros, I have a different brand DVR. Can the KBS3 be interfaced with a ptz cam directly? My dvr has ptz control but the on screen gui is dismal and doesn't have all functions on it.

My ptz cam is a Genie dvr is avtech



The RS485 socket used on the DM controller is a dec MMJ 6 pin



http://pinouts.ru/connector/6_pin_MMJ_female_connector.shtml



Does anyone know the pin designations that DM use on this socket? If someone knows the power supply voltage and correct pins? I have access to some test gear and should be able to use it for my needs once I can safely power it up, or at least find out if it wont do what I want. Any help would be very much appreciated.

[steve w 0]

Ok well I stripped the unit the KBS3 and started tracing some pins Dedicated Micros seem to have used the MMJ 6 pin connector as follows.



Pin 1 V+

Pins 2 5 and 6 V-

pins 3 and 4 data



I think Ill be back asking more questions very soon I'm sure.





Power connected confirmed correct.

[cctvmann 0]

Ok well I stripped the unit the KBS3 and started tracing some pins Dedicated Micros seem to have used the MMJ 6 pin connector as follows.



Pin 1 V+

Pins 2 5 and 6 V-

pins 3 and 4 data



I think Ill be back asking more questions very soon I'm sure.





Power connected confirmed correct.

the kbs3 only can be used with the dm sprites or dvrs made by dm to suit the keyboard it cannot be used to move a ptz camera without the sprite/sprite 2
