RJ-11 video cables into RG-45 Baluns Help

[muinchja 0]

So I have some cameras that use RJ-11 cables for video and power, but my monitor that receives the video and provides the power has died. I have a four channel multiplexor with BNC inputs. I found some BNC to RJ-45 video balun connector with power adapters which i bought with out realizing I had RJ-11 cables. I thought i could just "re-plug" the end of the cable with a cat6 plug, but the two wiring diagrams don't match as nicely as I had hoped. I don't need audio or PTZ, just video and power. Does anyone have any suggestions for matching the wires correctly?



[evildog1 0]

Hi, i can help u, with this and there is a cheap way and its easy, i,ll get back to you in a few hours as i gotta get work now, i post how to do it with pic when i gets home



Also can upload a photo of the end of cable from cam u want to run to the dvr

[evildog1 0]

hi, this many help





here is the connectors



http://www.ebay.com/itm/320957424758?ssPageName=STRK:MEWNX:IT&_trksid=p3984.m1439.l2649



Run Pin 3 "Ground wire" to the -of the power BNC then

then run another black wire to the - ground of the video bnc



then run pin 6 to the power bnc + as showen in photo



then run pin 2 to the + of the video BNC as Showen in the photo



and here how to do it in the photo





hope it help please let me know if it do, good luck
