leom 0 Posted August 1, 2014 Hi, I have a problem with an 2CD7153-e camera. After a firmware update no boot, the camera was bricked. So i do some research and now i know that the ip address of the camera is 192.0.0.64. After that i want to update the firmware with TFTP tool but when i do it the soft try to upload the firmware and then restart the upload a second third etc .. time. After i tried to connect the camera through serial com with hyperterminal. This ok but i can't do any command for exemple the ctrl+U for upload firmware. and when i let the camera to boot i have some error and corrupt files. Anybody can help me ? Thank Leo Share this post Link to post Share on other sites
iTuneDVR 2 Posted August 1, 2014 PC ethernet card IP=192.0.0.128 Start up Hikvision TFTP Server with digicap.dav file in directory. Connect IPC to you network or PC. Power on IPC. (Defalt IPC IP=192.0.0.64) Look In TFTP window and you will see some messages! Don't forget close TFTP Server after finish message! Share this post Link to post Share on other sites
leom 0 Posted August 2, 2014 Yes i had done that but it don't work. that is a part of the log: [2014-07-29 19:58:33] TFTP server[192.0.0.128] initialized [2014-07-29 19:58:50] Device[192.0.0.64] test tftpserver [2014-07-29 19:58:50] Connect client[192.0.0.64] success [2014-07-29 19:58:50] Start file[C:\TFTP-Auto-Update\digicap.dav] transmitting [2014-07-29 20:00:47] TFTP server[192.0.0.128] initialized [2014-07-29 20:00:55] Device[192.0.0.64] test tftpserver [2014-07-29 20:00:55] Connect client[192.0.0.64] success [2014-07-29 20:00:55] Start file[C:\TFTP-Auto-Update\digicap.dav] transmitting [2014-07-29 20:01:14] Device[192.0.0.64] test tftpserver [2014-07-29 20:01:14] Connect client[192.0.0.64] success [2014-07-29 20:01:14] Start file[C:\TFTP-Auto-Update\digicap.dav] transmitting [2014-07-29 20:01:34] Device[192.0.0.64] test tftpserver [2014-07-29 20:01:34] Connect client[192.0.0.64] success [2014-07-29 20:01:34] Start file[C:\TFTP-Auto-Update\digicap.dav] transmitting [2014-07-29 20:01:53] Device[192.0.0.64] test tftpserver [2014-07-29 20:01:53] Connect client[192.0.0.64] success Share this post Link to post Share on other sites
iTuneDVR 2 Posted August 3, 2014 Don't forget close TFTP Server after finish message! Share this post Link to post Share on other sites
leom 0 Posted August 3, 2014 there is no finish message the tftp server reboot all time. Share this post Link to post Share on other sites
