dx2 0 Posted May 23, 2015 In order to avoid a very long post, I attached the log as text document. It begins with boot, stopping boot to update firmware, changing IP address of TFTP server in order to be found by DVR, loading firmware, resume booting, restart. After restart is new full, non-interrupted booting loop. Lines starting with several equal "=====" characters are my intervention points with explanations or only explanations of the booting process. Thank you for your support, Daniel boot_update_log.zip Share this post Link to post Share on other sites
iTuneDVR 2 Posted May 23, 2015 In order to avoid a very long post, I attached the log as text document.It begins with boot, stopping boot to update firmware, changing IP address of TFTP server in order to be found by DVR, loading firmware, resume booting, restart. After restart is new full, non-interrupted booting loop. Lines starting with several equal "=====" characters are my intervention points with explanations or only explanations of the booting process. Thank you for your support, Daniel From your boot log U-Boot 1.2.0 (Nov 19 2009 - 16:28:58)DRAM: 256 MB numonyx flash devid:0x227e id3:0x2221 id4:0x2200 ARM Clock : 364MHz DDR Clock : 310MHz Hit ctrl+u to stop autoboot: 0 HKVS # update ======================Here I entered "update" command, having TFTP server on 192.0.0.128 TFTP from server 192.168.1.15; our IP address is 192.168.1.64 Filename 'digicap.dav'. Load address: 0x81200000 Loading: T T T T T T T T Abort HKVS # update ======================Here I entered "update" command, after changing TFTP server address to 192.168.1.15, as DVR requested at previous command TFTP from server 192.168.1.15; our IP address is 192.168.1.64 Filename 'digicap.dav'. Load address: 0x81200000 Loading: ################################################################# ################################################################# ################################################################# ################################################################# ################################################################# ################################################################# ################################################################# ################################################################# ################################################################# ################################################################# ################################################################# ################################################################# ################################################################# ################################################################# ################################################################# ################################################################# ################################################################# ################################################################# ################################################################# ################################################################# ################################################################# ################################################################# ################################################################# ################################################################# ################################################################# ################################################################# ################################################################# ################################################################# ################################################################# ################################################################# #### done Bytes transferred = 10000988 (989a5c hex) jffs2: add update file(uImage)...(1569292B->1580004B)done. jffs2: add update file(rootfs.img)...(714721B->722692B)done. jffs2: add update file(720.422)...(829440B->75324B)done. jffs2: add update file(ds8062_fpga.rbf)...(269846B->231764B)done. jffs2: add update file(initrun.sh)...(459B->396B)done. jffs2: add update file(preAllocMem)...(4704B->2388B)done. jffs2: add update file(waitAllocMem)...(3232B->1556B)done. jffs2: add update file(guirc.tar.gz)...(5072087B->5145416B)done. jffs2: add update file(webs.tar.gz)...(1536747B->1563068B)done. Un-Protect Flash space Un-Protected 122 sectors erase Flash space Erase Operation Completed. Erased 122 sectors Writing jffs2 to Flash.../done Re-Protect Flash space Protected 122 sectors HKVS # HKVS # bootd =====================================Here I started the booting process by entering "bootd" command ### JFFS2 loading 'uImage' to 0x80700000 jffs2: scanning filesystem . done. ### JFFS2 load complete: 1569292 bytes loaded to 0x80700000 ## Booting image at 80700000 ... Image Name: Linux-2.6.10_mvl401-davinci_evm Image Type: ARM Linux Kernel Image (uncompressed) Data Size: 1569228 Bytes = 1.5 MB Load Address: 80008000 Entry Point: 80008000 Verifying Checksum ... OK OK Starting kernel ... Uncompressing Linux... done, booting the kernel. BusyBox v1.2.1 (2009.08.25-02:50+0000) Built-in shell (ash) Enter 'help' for a list of davinci system commands. Creating initial udev device nodes ... done. mount jffs2 filesystem done. waiting allocate memory... before allocArmMemory after allocArmMemory, vAddr:0x0x40065000, pAddr:0x0x83000000 start compress. waiting decompression... insmod: cannot insert `ky2009.ko': No such device (-1): No such device bootParms.encodeChans 16 bootParms.decodeChans 1 devHardInfo.encodeChans 16 devHardInfo.decodeChans 1 devHardInfo.alarmInNums = 16 devHardInfo.alarmOutNums = 4 devHardInfo.ataCtrlNums = 4 devHardInfo.decodeChans = 16 devHardInfo.dspSoftwareBuildDate = 0x0 devHardInfo.dspSoftwareVersion = 0x0 devHardInfo.encodeChans = 16 devHardInfo.hardwareVersion = 0xb300 devHardInfo.networkNums = 1 devHardInfo.panelVersion = 0 devHardInfo.ramSize = 256 devHardInfo.softwareBuildDate = 0x0 devHardInfo.softwareVersion = 0x0 devModel = DS-8116HDI-S insmod: cannot insert `ky2009.ko': No such device (-1): No such device Say your DVR good bye!!! Your DSP processor is broken!!! Time is ower! Sorry Share this post Link to post Share on other sites
dx2 0 Posted May 23, 2015 Bad news, right? Any chance to replace the chip? Any idea which one is it? I loved very much this DVR because of its 16 inputs of audio and 16in/4out alarm contacts. Share this post Link to post Share on other sites
iTuneDVR 2 Posted May 23, 2015 Bad news, right?Any chance to replace the chip? Yes. If you find this DSP and change it in your DVR, then..... But i think forget about this DVR and jush buy new. Any idea which one is it? I loved very much this DVR because of its 16 inputs of audio and 16in/4out alarm contacts. Maybe both. Share this post Link to post Share on other sites
autotecindia 0 Posted February 1, 2016 Dear Sir, Please help i am Using Hikvision DVR DS-7304HVI-ST, it stuck on loading screen so du have solution for this please send Regards Vinay Inani Share this post Link to post Share on other sites
iTuneDVR 2 Posted February 1, 2016 Dear Sir, Please help i am Using Hikvision DVR DS-7304HVI-ST, it stuck on loading screen so du have solution for this please send Regards Vinay Inani Console log from TTL? Share this post Link to post Share on other sites
dx2 0 Posted February 1, 2016 Unfortunately no solution yet. Share this post Link to post Share on other sites
dush78 0 Posted October 8, 2018 If you need the latest firmware or TFTP loader let me know and i will send them to you. Hi i need the firmware and TFTP loader. can you please send to me ? Share this post Link to post Share on other sites
antonio1 0 Posted January 24, 2019 you guy are really good, I wonder could you help me? I have everything needed prepared, tools, firmware and the console. The problem is that update command does not work, but if I try to update manually using lines commands seems to work loading but does not boot with the new firmware just loaded. Could you please have a look over my console log to give a hint what to do? My device is Hikvision DVR DS-7208HUHI-K2. U-Boot 2010.06-svn (May 25 2017 - 18:00:13)[V1.4.5] Hit ctrl+u to stop autoboot: 0 HKVS $ setenv ipaddr 192.0.0.64 HKVS $ setenv serverip 192.0.0.128 HKVS $ setenv bootargs console=ttyS2,115200n8 root=/dev/ram0 rw initrd=0x42000000 HKVS $ setenv bootcmd 'tftp 0xc0700000 uImage; tftp 0x42000000 digicap.dav; bootm 0xc0700000' timeout for link [4999]! MAC: B4-A3-82-BC-57-15 TFTP from server 192.0.0.128; our IP address is 192.0.0.64 Download Filename 'digicap.dav'. Download to address: 0x42000000 Downloading: ################################################# done Bytes transferred = 17772908 (10f316c hex) data abort pc : [<4dc1038c>] lr : [<4dc1078c>] sp : 4d9ff0f0 ip : 4d9ff62a fp : 4dc38488 r10: 4d9ff194 r9 : 00000000 r8 : 4d9fffe0 r7 : 00000000 r6 : c0700000 r5 : 4dc3b004 r4 : c0700000 r3 : 00000000 r2 : 00000010 r1 : 00000000 r0 : c0700000 Flags: nZCv IRQs off FIQs off Mode SVC_32 Resetting CPU ... resetting ... U-Boot 2010.06-svn (May 25 2017 - 18:00:13)[V1.4.5] Hit ctrl+u to stop autoboot: 0 ### CRAMFS load complete: 4233112 bytes loaded to 0x42000000 ## Booting kernel from Legacy Image at 42000000 ... Verifying RSA ... OK Loading Kernel Image ... OK OK Starting kernel ... [ 4.682865] init(1) called reboot syscall, cmd: 0x0. Thu Jan 1 00:00:04 UTC 1970 mv: can't rename 'ubi*': No such file or directory Starting udev: [ OK ] /usr/bin/hrsaverify: verify "/tmp/start.sh" success! /usr/bin/hrsaverify: truncate "/tmp/start.sh" to 6528(1980 hex) success! sdbg: serverip:192.0.0.128 fastboot is language is 1 devtype is ab67 / ----------<1> tar guir webs ---------- BusyBox v1.2.1 Protect Shell (psh) Enter 'help' for a list of davinci system commands. # [ 9.178225] hi_gmac_v200 100a0000.ethernet eth0: Link is Up - 1Gbps/Full - flow control rx/tx ded in[/home/hik/gui_res.tar.lzma]/out[/home/app/gui_res.tar.lzma] ioctl faild. errno[5] tar: unexpected EOF tar: short read ----------<2> show logo ---------- read: pDevCfg->cfgHead.paraVersionis [0x170816]; read: iCkSum is [0x82d]; pDevCfg->cfgHead.paraChecksum is [0x82d] scriptCmd: ./load -i 0. ./load: line 30: 0x1c: not found a is ab67 b is 0xffe20888 AD pll is VI_CLOSE_NUM is 0 DS_7208HU_K DS_7108HU_K mmz allot OK DS_7208HUH_K loadKY2017 Start ./load: line 30: c: not found 0x120F0800: 0x00000170 --> 0x00000038 [END] 0x120f0898: 0x00000170 --> 0x00000038 [END] ViCloseCnt is Not All Closed close tde module alpha filter loadAd tp2823:0,tp2824:0,tp2833C:2,tp2827C:0,tp2828:0,nvp6114a:0 nvp6124b:0 nvp6134:2,nvp6134b:0 cmdBuf:insmod extdrv/tp2823.ko I2C_dev_Choose=1 cmdBuf:insmod extdrv/nvp6134_ex.ko I2C_dev_Choose=1 insert audio load K71 ok / ----------<4> del no use res ---------- cp: can't stat '/home/app/hisi/modules/setDebug_mux': No such file or directory start savelog proc!!!!! iSCSI daemon with pid=373 started!Jan 8 17:56:33 udevd-work[130]: kernel-provided name 'sdb' and NAME= 'sdf' disagree, please use SYMLINK+= or change the kernel to provide the proper name fun:hisi_main_module_init, line:11183 >>>>>>ATA is Not Scan Done! Please Wait<<<<<< pdev_hard_info->ataCtrlNums=2 file:src/pal_api.c,line:576, pal_module_init successfully [CRIT]read_execl_guide_cfg()1157:start [INFO]get_flash_cards_info()410:ignore [msmouse]. [CRIT]get_flash_cards_info()451:********can not find any usb device!******** [CRIT]read_execl_guide_cfg()1167:get flash cards info failed. iRet[-1] read execl guide cfg failed. iRet[-1]file:src/pal_api.c,line:537, pal_module_init has been called remove error hisi_bsp_info_close[1] :1 t1: wait storage [2] and gui[2] and hicore[2] and ipcm[0] and toolserver[0] fun:hisi_watchdog_init, line:5487 hisi_watchdog_init(/dev/watchdog, 28) ok iDogTimeOut:25 Sec! /*********************init_global_error_lib*/, init_global_error_lib start! ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~phy on eth0 is link up -----------------get_net_link status == 1 :1 init_lzma_mem alloc size 1048576 initNetIf set_eth_mode start ======== [DHCP] default pIpAddr: 192.168.1.64, pNetMask: 255.255.255.0 fun:hisi_dsp_init, line:2819 --------------init dsp -------------------- <LIB>DspInitParaAllocMem OK! addr is 0xb4400000 fun:hisi_main_dsp_init, line:1990 Device Main Vo Chan is 2[0] menuDispChan = 0 This is new 2827! <LIB>Func: AppMapShareMemPool, line 917, PoolMode:0 chan 0 Now Use OS Mem, not MMZ MEM <LIB>Func: AppMapShareMemPool, line 917, PoolMode:1 chan 0 Now Use OS Mem, not MMZ MEM <LIB>Func: AppMapShareMemPool, line 917, PoolMode:0 chan 1 Now Use OS Mem, not MMZ MEM <LIB>Func: AppMapShareMemPool, line 917, PoolMode:1 chan 1 Now Use OS Mem, not MMZ MEM <LIB>Func: AppMapShareMemPool, line 917, PoolMode:0 chan 2 Now Use OS Mem, not MMZ MEM <LIB>Func: AppMapShareMemPool, line 917, PoolMode:1 chan 2 Now Use OS Mem, not MMZ MEM <LIB>Func: AppMapShareMemPool, line 917, PoolMode:0 chan 3 Now Use OS Mem, not MMZ MEM <LIB>Func: AppMapShareMemPool, line 917, PoolMode:1 chan 3 Now Use OS Mem, not MMZ MEM <LIB>Func: AppMapShareMemPool, line 917, PoolMode:0 chan 4 Now Use OS Mem, not MMZ MEM <LIB>Func: AppMapShareMemPool, line 917, PoolMode:1 chan 4 Now Use OS Mem, not MMZ MEM <LIB>Func: AppMapShareMemPool, line 917, PoolMode:0 chan 5 Now Use OS Mem, not MMZ MEM <LIB>Func: AppMapShareMemPool, line 917, PoolMode:1 chan 5 Now Use OS Mem, not MMZ MEM <LIB>Func: AppMapShareMemPool, line 917, PoolMode:0 chan 6 Now Use OS Mem, not MMZ MEM <LIB>Func: AppMapShareMemPool, line 917, PoolMode:1 chan 6 Now Use OS Mem, not MMZ MEM <LIB>Func: AppMapShareMemPool, li[ 19.802549] hi_gmac_v200 100a0000.ethernet eth0: Link is Down ne 917, PoolMode:0 chan 7 Now Use OS Mem, not MMZ MEM <LIB>Func: AppMapShareMemPool, line 917, PoolMode:1 chan 7 Now Use OS Mem, not MMZ MEM Chan[0] Sup Borrow MMZ memory to meet ana net pool[2]! <LIB>Func: AppMapShareMemPool, line 917, PoolMode:3 chan 0 Now Use OS Mem, not MMZ MEM Chan[1] Sup Borrow MMZ memory to meet ana net pool[2]! <LIB>Func: AppMapShareMemPool, line 917, PoolMode:3 chan 1 Now Use OS Mem, not MMZ MEM Chan[2] Sup Borrow MMZ memory to meet ana net pool[2]! <LIB>Func: AppMapShareMemPool, line 917, PoolMode:3 chan 2 Now Use OS Mem, not MMZ MEM Chan[3] Sup Borrow MMZ memory to meet ana net pool[2]! <LIB>Func: AppMapShareMemPool, line 917, PoolMode:3 chan 3 Now Use OS Mem, not MMZ MEM Chan[4] Sup Borrow MMZ memory to meet ana net pool[2]! <LIB>Func: AppMapShareMemPool, line 917, PoolMode:3 chan 4 Now Use OS Mem, not MMZ MEM Chan[5] Sup Borrow MMZ memory to meet ana net pool[2]! <LIB>Func: AppMapShareMemPool, line 917, PoolMode:3 chan 5 Now Use OS Mem, not MMZ MEM Chan[6] Sup Borrow MMZ memory to meet ana net pool[2]! <LIB>Func: AppMapShareMemPool, line 917, PoolMode:3 chan 6 Now Use OS Mem, not MMZ MEM Chan[7] Sup Borrow MMZ memory to meet ana net pool[2]! <LIB>Func: AppMapShareMemPool, line 917, PoolMode:3 chan 7 Now Use OS Mem, not MMZ MEM <LIB>Func: AppMapShareMemPool, line 917, PoolMode:6 chan 0 Now Use OS Mem, not MMZ MEM Chan[0] Sup Borrow MMZ memory to meet ipc net pool[7]! <LIB>Func: AppMapShareMemPool, line 917, PoolMode:6 chan 1 Now Use OS Mem, not MMZ MEM Chan[1] Sup Borrow MMZ memory to meet ipc net pool[7]! <LIB>Func: AppMapShareMemPool, line 917, PoolMode:6 chan 2 Now Use OS Mem, not MMZ MEM Chan[2] Sup Borrow MMZ memory to meet ipc net pool[7]! <LIB>Func: AppMapShareMemPool, line 917, PoolMode:6 chan 3 Now Use OS Mem, not MMZ MEM Chan[3] Sup Borrow MMZ memory to meet ipc net pool[7]! <LIB>Func: AppMapShareMemPool, line 917, PoolMode:4 chan 0 Now Use OS Mem, not MMZ MEM <LIB>Func: AppMapShareMemPool, line 917, PoolMode:5 chan 0 Now Use OS Mem, not MMZ MEM <LIB>Func: AppMapShareMemPool, line 917, PoolMode:4 chan 1 Now Use OS Mem, not MMZ MEM <LIB>Func: AppMapShareMemPool, line 917, PoolMode:5 chan 1 Now Use OS Mem, not MMZ MEM <LIB>Func: AppMapShareMemPool, line 917, PoolMode:4 chan 2 Now Use OS Mem, not MMZ MEM <LIB>Func: AppMapShareMemPool, line 917, PoolMode:5 chan 2 Now Use OS Mem, not MMZ MEM <LIB>Func: AppMapShareMemPool, line 917, PoolMode:4 chan 3 Now Use OS Mem, not MMZ MEM <LIB>Func: AppMapShareMemPool, line 917, PoolMode:5 chan 3 Now Use OS Mem, not MMZ MEM <LIB>Func: AppMapShareMemPool, line 917, PoolMode:10 chan 0 Now Use OS Mem, not MMZ MEM <LIB>Func: AppMapShareMemPool, line 917, PoolMode:12 chan 0 Now Use OS Mem, not MMZ MEM <LIB>Func: AppMapShareMemPool, line 917, PoolMode:12 chan 1 Now Use OS Mem, not MMZ MEM <LIB>Func: AppMapShareMemPool, line 917, PoolMode:12 chan 2 Now Use OS Mem, not MMZ MEM <LIB>Func: AppMapShareMemPool, line 917, PoolMode:12 chan 3 Now Use OS Mem, not MMZ MEM <LIB>*** [APP_PROCESS] DSP_LIB Build Time: [Sep 28 2018 19:04:59] *** sizeof(DSPINITPARA) 3109016 <DSP> pos error ---[InitPosMem] err, not support pos--- [ 24.308757] hi_gmac_v200 100a0000.ethernet eth0: Link is Up - 1Gbps/Full - flow control rx/tx 111vcaVpssGroup = 27 111vcaVpssGroup = 28 <DSP>vca DspVcaInitOsd OK! <DSP>vca Init vca success <DSP>vca DspVcaInitMetaDataPack: ok <DSP>vca DspVcaScdInit chanNum = 2 <DSP>vca scdChan:0 <DSP>vca scdChan:1 <DSP>vca DspVcaScdInit OK! <DSP>vca smdChan:0 <DSP>vca smdChan:1 <LIB>AppAllocLogoShareBuf 1. u32TotalShareBufSize:5308416 ShareLogoVirAddr:0xaffd4000 <LIB>AppAllocLogoShareBuf 2. u32TotalShareBufSize:5373952 ShareExtLogoVirAddr:0xaffc4000 <LIB>AppAllocLogoShareBuf is OK <LIB>1.Share Buffer Size 27394048 <LIB>2.Share Buffer Size 31719424 <LIB>3.Share Buffer Size 35061760 <LIB><AppAllocMenuMem> dispMode 5 <LIB>chan 0, menuShareBuf virtRgbAddr is 0xad3a2000, menuBufSize 16588800 <LIB>chan 1, menuShareBuf virtRgbAddr is 0xad2d7000, menuBufSize 829440 <LIB>4.Share Buffer Size 70305792 <LIB>DspAllocShareMemSize OK Total Share Buffer Size 70305792 <LIB>pid:379 tid:502 name:tskPlusDataFunc <LIB>startMagic :DSP_START_OK hisi_main_dsp_init:DSPINITPARA=3109016 ************g_pDspInitPara[0xb4400000], menuShareBuf 0[0xb44700f4, pAddr=0x8f2e2000, vAddr=0xad3a2000, w:3840,h2160,p:3840] 1[0xb4470108, pAddr=0x902b4000, vAddr=0xad2d7000, w:720,h576,p:720], hisi_freelogo_buffer is succsse 0 fun:hisi_dsp_init, line:2840 ------ dsp is init Ok iRetVal:0--------- !!!!!!!!!!!!!!!!!!!!!!!!!DSP Init Ok!!!!!!!!!!!!!!!!!!!!!!!!!!!!! fun:hisi_fill_4_screen_param, line:1739 window dispInfo[w:1920, h:1080], step(960, 536), last(960, 960) fun:hisi_fill_8_screen_param, line:1937 window dispInfo[w:704, h:576], step(176, 144), last(176, 144) <LIB>PhyAddr 0x94f74000, VirAddr 0xabd6b000, size 1048576 APPLY OK!!! fun:hisi_get_mem_from_dsp, line:364 VirAddr: 0xabd6b000, PhyAddr: 0x94f74000 init_stream_buf, pInStreamBuf:0xabd6b000, pOutStreamBuf:0xabdeb000 ------------> pthreadSpawn handle_pppoe_cfg_cmd wait storage [2] and gui[2] ===================handle_pppoe_cfg_cmd===================== =============pppoe============FOREVER===================================== :1 :1 <LIB>PhyAddr 0x95074000, VirAddr 0xab1f3000, size 1048576 APPLY OK!!! fun:hisi_get_mem_from_dsp, line:364 VirAddr: 0xab1f3000, PhyAddr: 0x95074000 maxIPCcount[12] maxAnalogCount[8] t1: wait storage [0] and gui[0] and hicore[0] and ipcm[0] and toolserver[0] part /dev/sda stor_get_db_total_files alloc 148 byte mem. part /dev/sda stor_get_record_file_detail_task beging 669400 part /dev/sda stor_get_record_file_detail_task :db_update_curdb_range_time start 669400 ### key info: [ipcm_svc_init]ipcm svc inited. ### <LIB>PhyAddr 0x951d7000, VirAddr 0xa9b3f000, size 65536 APPLY OK!!! fun:hisi_get_mem_from_dsp, line:364 VirAddr: 0xa9b3f000, PhyAddr: 0x951d7000 <LIB>PhyAddr 0x951e7000, VirAddr 0xa9b2f000, size 65536 APPLY OK!!! fun:hisi_get_mem_from_dsp, line:364 VirAddr: 0xa9b2f000, PhyAddr: 0x951e7000 <LIB>PhyAddr 0x951f7000, VirAddr 0xa9b1f000, size 65536 APPLY OK!!! fun:hisi_get_mem_from_dsp, line:364 VirAddr: 0xa9b1f000, PhyAddr: 0x951f7000 <LIB>PhyAddr 0x95207000, VirAddr 0xa9b0f000, size 65536 APPLY OK!!! fun:hisi_get_mem_from_dsp, line:364 VirAddr: 0xa9b0f000, PhyAddr: 0x95207000 <LIB>PhyAddr 0x95217000, VirAddr 0xa9aff000, size 65536 APPLY OK!!! fun:hisi_get_mem_from_dsp, line:364 VirAddr: 0xa9aff000, PhyAddr: 0x95217000 <LIB>PhyAddr 0x95227000, VirAddr 0xa9aef000, size 65536 APPLY OK!!! fun:hisi_get_mem_from_dsp, line:364 VirAddr: 0xa9aef000, PhyAddr: 0x95227000 <LIB>PhyAddr 0x95237000, VirAddr 0xa9adf000, size 65536 APPLY OK!!! fun:hisi_get_mem_from_dsp, line:364 VirAddr: 0xa9adf000, PhyAddr: 0x95237000 <LIB>PhyAddr 0x95247000, VirAddr 0xa9acf000, size 65536 APPLY OK!!! fun:hisi_get_mem_from_dsp, line:364 VirAddr: 0xa9acf000, PhyAddr: 0x95247000 <LIB>PhyAddr 0x95257000, VirAddr 0xa9abf000, size 65536 APPLY OK!!! fun:hisi_get_mem_from_dsp, line:364 VirAddr: 0xa9abf000, PhyAddr: 0x95257000 <LIB>PhyAddr 0x95267000, VirAddr 0xa9aaf000, size 65536 APPLY OK!!! fun:hisi_get_mem_from_dsp, line:364 VirAddr: 0xa9aaf000, PhyAddr: 0x95267000 <LIB>PhyAddr 0x95277000, VirAddr 0xa9a9f000, size 65536 APPLY OK!!! fun:hisi_get_mem_from_dsp, line:364 VirAddr: 0xa9a9f000, PhyAddr: 0x95277000 <LIB>PhyAddr 0x95287000, VirAddr 0xa9a8f000, size 65536 APPLY OK!!! fun:hisi_get_mem_from_dsp, line:364 VirAddr: 0xa9a8f000, PhyAddr: 0x95287000 <LIB>PhyAddr 0x95297000, VirAddr 0xa9a7f000, size 65536 APPLY OK!!! fun:hisi_get_mem_from_dsp, line:364 VirAddr: 0xa9a7f000, PhyAddr: 0x95297000 <LIB>PhyAddr 0x952a7000, VirAddr 0xa9a6f000, size 65536 APPLY OK!!! fun:hisi_get_mem_from_dsp, line:364 VirAddr: 0xa9a6f000, PhyAddr: 0x952a7000 <LIB>PhyAddr 0x952b7000, VirAddr 0xa9a5f000, size 65536 APPLY OK!!! fun:hisi_get_mem_from_dsp, line:364 VirAddr: 0xa9a5f000, PhyAddr: 0x952b7000 <LIB>PhyAddr 0x952c7000, VirAddr 0xa9a4f000, size 65536 APPLY OK!!! fun:hisi_get_mem_from_dsp, line:364 VirAddr: 0xa9a4f000, PhyAddr: 0x952c7000 <LIB>PhyAddr 0x952d7000, VirAddr 0xa99cf000, size 524288 APPLY OK!!! fun:hisi_get_mem_from_dsp, line:364 VirAddr: 0xa99cf000, PhyAddr: 0x952d7000 <LIB>PhyAddr 0x95357000, VirAddr 0xa994f000, size 524288 APPLY OK!!! fun:hisi_get_mem_from_dsp, line:364 VirAddr: 0xa994f000, PhyAddr: 0x95357000 <LIB>PhyAddr 0x953d7000, VirAddr 0xa98cf000, size 524288 APPLY OK!!! fun:hisi_get_mem_from_dsp, line:364 VirAddr: 0xa98cf000, PhyAddr: 0x953d7000 <LIB>PhyAddr 0x95457000, VirAddr 0xa984f000, size 524288 APPLY OK!!! fun:hisi_get_mem_from_dsp, line:364 VirAddr: 0xa984f000, PhyAddr: 0x95457000 big_bit_mask p[0xabd65708], idx[-1] error!func[big_bit_mask],line[63] +++++++++++++++++++First save_error_no, time_t:669375 [01-08 17:56:41][2][695]check remote session thread begin [01-08 17:56:41][2][698]check file session heartbeat begin viLostProc:Chan 1 VI lost. viLostProc:Chan 2 VI lost. [01-08 17:56:41][3][683]RemoteSession::~RemoteSession() [01-08 17:56:41][3][683]RemoteSession::Free [01-08 17:56:41][3][683]RemoteSession::~RemoteSession() [01-08 17:56:41][3][683]RemoteSession::Free [01-08 17:56:41][3][683]RemoteSession::~RemoteSession() [01-08 17:56:41][3][683]RemoteSession::Free [01-08 17:56:41][3][683]RemoteSession::~RemoteSession() [01-08 17:56:41][3][683]RemoteSession::Free [01-08 17:56:41][1][683]p2pLinkManage Destruct Ok tttttchan=1,vaddr=0xb494a000 #####line:1895,iChan[1],iInchan[61],bflag[2],iVideoType[0x72],currCompParaType[0x0],currEncResolution[0x1b] file[init/dvr.c],func[setSubStreamRecStatus],line[2004], iChan:[1],iRec:[0],iSubRec:[1] file[init/dvr.c],func[setSubStreamRecStatus],line[2005], iChan:[1],szRecCount:[1],szSubRecCount:[1] tttttchan=2,vaddr=0xb407e000 file[init/dvr.c],func[setSubStreamRecStatus],line[2004], iChan:[2],iRec:[0],iSubRec:[0] file[init/dvr.c],func[setSubStreamRecStatus],line[2005], iChan:[2],szRecCount:[1],szSubRecCount:[0] tttttchan=3,vaddr=0xb3cfc000 file[init/dvr.c],func[setSubStreamRecStatus],line[2004], iChan:[3],iRec:[0],iSubRec:[0] file[init/dvr.c],func[setSubStreamRecStatus],line[2005], iChan:[3],szRecCount:[1],szSubRecCount:[0] tttttchan=4,vaddr=0xb397a000 file[init/dvr.c],func[setSubStreamRecStatus],line[2004], iChan:[4],iRec:[0],iSubRec:[0] file[init/dvr.c],func[setSubStreamRecStatus],line[2005], iChan:[4],szRecCount:[1],szSubRecCount:[0] tttttchan=5,vaddr=0xb35f8000 file[init/dvr.c],func[setSubStreamRecStatus],line[2004], iChan:[5],iRec:[0],iSubRec:[0] file[init/dvr.c],func[setSubStreamRecStatus],line[2005], iChan:[5],szRecCount:[1],szSubRecCount:[0] tttttchan=6,vaddr=0xb3276000 file[init/dvr.c],func[setSubStreamRecStatus],line[2004], iChan:[6],iRec:[0],iSubRec:[0] file[init/dvr.c],func[setSubStreamRecStatus],line[2005], iChan:[6],szRecCount:[1],szSubRecCount:[0] tttttchan=7,vaddr=0xb2ef4000 file[init/dvr.c],func[setSubStreamRecStatus],line[2004], iChan:[7],iRec:[0],iSubRec:[0] file[init/dvr.c],func[setSubStreamRecStatus],line[2005], iChan:[7],szRecCount:[1],szSubRecCount:[0] tttttchan=8,vaddr=0xb2b72000 file[init/dvr.c],func[setSubStreamRecStatus],line[2004], iChan:[8],iRec:[0],iSubRec:[0] file[init/dvr.c],func[setSubStreamRecStatus],line[2005], iChan:[8],szRecCount:[1],szSubRecCount:[0] @@@@do not need poc test@@@@ !!!!!!!!!!!!!!!sc_hicore is start ok!!!!!!!!!!!!!!!! START SMD!!!!!!!!!! <DSP>vca 11QueVcaChan vcaChan:0,realChan:0 <DSP>vca DspVcaSmdQueChan smdChan:0,vcaChan:0 <DSP>vca 1HostSMDStart 704, 576 pSmdCtrl->analyseParam.VcaWidth = 176, pSmdCtrl->analyseParam.VcaHeight = 144 <DSP>vca SMD_Open ok,vcaW:176,vcaH:144 <DSP>vca dst 7 27 2 <DSP>vca fun:DspVcaSetDataFrameRate src:30,dst:12 <DSP>vca chan 0 HostStartSmd success <DSP>vca chan 0 set SMD rule successa <DSP>vca rule_num:1 <DSP>vca ID:1, TYPE:0, event_type:1 <DSP>vca x:0.237000, y:0.469000 <DSP>vca x:0.526000, y:0.316000 START SMD!!!!!!!!!! <DSP>vca 11QueVcaChan vcaChan:1,realChan:1 <DSP>vca DspVcaSmdQueChan smdChan:1,vcaChan:1 <DSP>vca 1HostSMDStart 704, 576 pSmdCtrl->analyseParam.VcaWidth = 176, pSmdCtrl->analyseParam.VcaHeight = 144 <DSP>vca SMD_Open ok,vcaW:176,vcaH:144 <DSP>vca dst 7 28 2 <DSP>vca fun:DspVcaSetDataFrameRate src:30,dst:12 <DSP>vca chan 1 HostStartSmd success <DSP>vca chan 1 set SMD rule successa <DSP>vca rule_num:1 <DSP>vca ID:1, TYPE:0, event_type:1 <DSP>vca x:0.795000, y:0.847000 <DSP>vca x:0.942000, y:0.436000 file:smd/smd_proc.c,line:2256, smdCtrlTask:set chan smd failed. file:smd/smd_proc.c,line:2256, smdCtrlTask:set chan smd failed. file:smd/smd_proc.c,line:2256, smdCtrlTask:set chan smd failed. file:smd/smd_proc.c,line:2256, smdCtrlTask:set chan smd failed. file:smd/smd_proc.c,line:2256, smdCtrlTask:set chan smd failed. file:smd/smd_proc.c,line:2256, smdCtrlTask:set chan smd failed. file:smd/smd_proc.c,line:2256, smdCtrlTask:set chan smd failed. file:smd/smd_proc.c,line:2256, smdCtrlTask:set chan smd failed. file:smd/smd_proc.c,line:2256, smdCtrlTask:set chan smd failed. file:smd/smd_proc.c,line:2256, smdCtrlTask:set chan smd failed. file:smd/smd_proc.c,line:2256, smdCtrlTask:set chan smd failed. file:smd/smd_proc.c,line:2256, smdCtrlTask:set chan smd failed. read_rs485: recv data 1 0 @@@@do not need poc test@@@@ Device Is Ready 1+0 records in 1+0 records out 65536 bytes (64.0KB) copied, 0.008619 seconds, 7.3MB/s [ERROR]:savelog.c[1140] iCurrTime[669402] iTempTime[668178] [ERROR]:savelog.c[1326] flash can not be Operate and quit! LibLibLib: <HIKVQD_Process> pass at line:1158 LibLibLib: <HIKVQD_Process> pass at line:1158 Share this post Link to post Share on other sites
OnofreiCatalin 0 Posted January 24, 2019 Hello, i am also having problems with hikvision ds 7204 hqhi h1/a...it crashed afer an firmware upgrade..... trid with putty but i cant pass the HKVS $ command...it dowsnt respond to update or other commands... in TFTP i'm getting this error... Open file[C:\TFTP\TFTP\econt_Vision-AV2000?] failure any ideas ? here's my log : [ 44.334817] [HKBSP][hik_wdt hik_wdt.1]hik-wdt:hikwdt_isr. Call hikwdt notifier chain! [ 44.342663] [HKBSP][hik_wdt hik_wdt.1]hik-wdt:hikwdt_isr. I'm so Sorry (>_<)... [ 44.349963] [HKBSP][hik_wdt hik_wdt.1]hik-wdt:hikwdt_isr. last_feedwdt:4294939170(jiffies64:4294941729timeout:25) U-Boot 2010.06-svn18487 (Nov 11 2017 - 13:44:08)[V1.4.5] Hit ctrl+u to stop autoboot: 0 ### CRAMFS load complete: 3499032 bytes loaded to 0x82000000 ## Booting kernel from Legacy Image at 82000000 ... Verifying RSA ... OK Loading Kernel Image ... OK OK Starting kernel ... [ 1.983033] init(1) called reboot syscall cmd: 0x0. Thu Jan 1 00:00:01 UTC 1970 mv: can't rename 'ubi*': No such file or directory Starting udev: [ OK ] /usr/bin/hrsaverify: verify "/tmp/start.sh" success! /usr/bin/hrsaverify: truncate "/tmp/start.sh" to 5904(1710 hex) success! sdbg: serverip:192.0.0.128 fastboot is language is 1 devtype is ab43 / ----------<1> tar guir webs ---------- BusyBox v1.2.1 Protect Shell (psh) Enter 'help' for a list of davinci system commands. # [ 5.058529] hi_gmac_v200 100a0000.ethernet eth0: Link is Up - 100Mbps/Full - flow control rx/tx ded in[/home/hik/gui_res.tar.lzma]/out[/home/app/gui_res.tar.lzma] ioctl faild. errno[5] tar: bad lzma header tar: short read ----------<2> show logo ---------- mv: can't rename '/home/app/exec/ss': No such file or directory chmod: /dev/ttyS3: No such file or directory read: pDevCfg->cfgHead.paraVersionis [0x170816]; read: iCkSum is [0x82f]; pDevCfg->cfgHead.paraChecksum is [0x82d] ckSum erroriCkSum=0x82fparaChecksum=0x82d! ERROR this is a new device please check!! scriptCmd: ./load -i 0. a is ab43 DS_7204HQK_K mmz allot DS_7204HQK_K 0x120F0800: 0x00000170 --> 0x00000038 [END] 0x120f084c: 0x00000170 --> 0x00000038 [END] close tde alpha filter loadAd tp2823:0tp2824:0tp2833C:1tp2827C:0tp2828:0nvp6114a:0 nvp6124b:0 nvp6134:0nvp6134b:0 cmdBuf:insmod extdrv/tp2823.ko insert audio load K72 ok / ----------<4> del no use res ---------- cp: can't stat '/home/app/hisi/modules/setDebug_mux': No such file or directory iSCSI daemon with pid=293 started!start savelog proc!!!!! pdev_hard_info->ataCtrlNums=1 file:src/pal_api.cline:574 pal_module_init successfully [CRIT]read_execl_guide_cfg()1157:start [INFO]get_flash_cards_info()410:ignore [msmouse]. [CRIT]get_flash_cards_info()451:********can not find any usb device!******** [CRIT]read_execl_guide_cfg()1167:get flash cards info failed. iRet[-1] read execl guide cfg failed. iRet[-1]file:src/pal_api.cline:535 pal_module_init has been called remove error hisi_bsp_info_close[1] :1 t1: wait storage [2] and gui[2] and hicore[2] and ipcm[0] and toolserver[0] fun:hisi_watchdog_init line:5486 hisi_watchdog_init(/dev/watchdog 28) ok iDogTimeOut:25 Sec! /*********************init_global_error_lib*/ init_global_error_lib start! ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~phy on eth0 is link up -----------------get_net_link status == 1 :1 init_lzma_mem alloc size 1048576 initNetIf set_eth_mode start ======== dns handle set eeeeeeeeeeeeeeee RTNETLINK answers: No such process RTNETLINK answers: No such process RTNETLINK answers: No such file or directory fun:hisi_dsp_init line:2819 --------------init dsp -------------------- fun:hisi_main_dsp_init line:1990 Device Main Vo Chan is 2[0] menuDispChan = 0 alloc anal channel net buffer failed ! alloc anal channel net buffer failed ! alloc anal channel net buffer failed ! alloc anal channel net buffer failed ! Chan[0] Sup Borrow MMZ memory to meet ipc net pool[6]! Chan[0] Sup Borrow MMZ memory to meet ipc net pool[7]! Chan[1] Sup Borrow MMZ memory to meet ipc net pool[6]! Chan[1] Sup Borrow MMZ memory to meet ipc net pool[7]! Chan[2] Sup Borrow MMZ memory to meet ipc net pool[6]! Chan[2] Sup Borrow MMZ memory to meet ipc net pool[7]! [ 13.540743] hi_gmac_v200 100a0000.ethernet eth0: Link is Down [ 15.637636] hi_gmac_v200 100a0000.ethernet eth0: Link is Up - 100Mbps/Full - flow control rx/tx 111vcaVpssGroup = 9 111vcaVpssGroup = 10 111vcaVpssGroup = 11 111vcaVpssGroup = 12 <DSP>vca DspVcaInitOsd OK! <DSP>vca Init vca success <DSP>vca DspVcaInitMetaDataPack: ok <DSP>vca DspVcaScdInit chanNum = 0 <DSP>vca DspVcaScdInit OK! <DSP>vca smdChan:0 <DSP>vca smdChan:1 <DSP>vca smdChan:2 <DSP>vca smdChan:3 hisi_main_dsp_init:DSPINITPARA=3108608 ************g_pDspInitPara[0xb4a94008] menuShareBuf 0[0xb4b040fc pAddr=0x91805000 vAddr=0xacf45000 w:1920h1200p:1920] 1[0xb4b04110 pAddr=0x0 vAddr=0x0 w:0h0p:0] hisi_freelogo_buffer is succsse 0 fun:hisi_dsp_init line:2840 ------ dsp is init Ok iRetVal:0--------- !!!!!!!!!!!!!!!!!!!!!!!!!DSP Init Ok!!!!!!!!!!!!!!!!!!!!!!!!!!!!! fun:hisi_fill_4_screen_param line:1739 window dispInfo[w:1920 h:1080] step(960 536) last(960 960) init_stream_buf pInStreamBuf:0xaac63008 pOutStreamBuf:0xaace3008 ------------> pthreadSpawn handle_pppoe_cfg_cmd wait storage [2] and gui[2] ===================handle_pppoe_cfg_cmd===================== =============pppoe============FOREVER===================================== :0 :0 maxIPCcount[5] maxAnalogCount[4] ### key info: [ipcm_svc_init]ipcm svc inited. ### fun:hisi_get_mem_from_dsp line:364 VirAddr: 0xa853b000 PhyAddr: 0x93750000 fun:hisi_get_mem_from_dsp line:364 VirAddr: 0xa84bb000 PhyAddr: 0x937d0000 big_bit_mask p[0xaac1d708] idx[-1] error!func[big_bit_mask]line[63] dyn ddns [01-25 00:33:48][2][516]check remote session thread begin [01-25 00:33:48][3][507]RemoteSession::~RemoteSession() [01-25 00:33:48][3][507]RemoteSession::Free [01-25 00:33:48][3][507]RemoteSession::~RemoteSession() [01-25 00:33:48][3][507]RemoteSession::Free [01-25 00:33:48][3][507]RemoteSession::~RemoteSession() [01-25 00:33:48][3][507]RemoteSession::Free [01-25 00:33:48][3][507]RemoteSession::~RemoteSession() [01-25 00:33:48][3][507]RemoteSession::Free [01-25 00:33:48][1][507]p2pLinkManage Destruct Ok [01-25 00:33:48][1][507]set config path is /usr/ezviz/opensdk [01-25 00:33:48][1][507]SET EZVIZ_LBS: litedev.eu.hik-connect.com:8666 WITHOUT INIT MICROKERNEL start_ezviz_service dinfo a80b4084 token a80b3c8c decrypt begin decrypt end [01-25 00:33:48][1][507]################ezviz main start################ [01-25 00:33:48][1][507]opensdk version: V1.5.51 build 180522 tttttchan=1vaddr=0xb4a12000 file[init/dvr.c]func[setSubStreamRecStatus]line[2003] iChan:[1]iRec:[0]iSubRec:[0] file[init/dvr.c]func[setSubStreamRecStatus]line[2004] iChan:[1]szRecCount:[1]szSubRecCount:[0] [01-25 00:33:48][1][507]################ezviz main start over################ [01-25 00:33:48][1][525]InitLocalSock ok [01-25 00:33:48][1][525]start microkernel [01-25 00:33:48][1][525]SET EZVIZ_LBS: litedev.eu.hik-connect.com:8666 WITHOUT INIT MICROKERNEL [01-25 00:33:48][1][525]microkernel use callback [01-25 00:33:48][1][525]microkernel_init lbs ip: litedev.eu.hik-connect.com [01-25 00:33:48][1][525]get key value [01-25 00:33:48][1][525]get key value [01-25 00:33:48][1][525]ezDevSDK_Init ret 0 [01-25 00:33:48][1][525]ezdev_sdk_kernel_common_module_load [01-25 00:33:48][1][525]All Module Is Load microkernerl start [01-25 00:33:48][1][525]ezdevsdk_init end ret 0 [01-25 00:33:48][1][525]microkernel start success start dev log ctrl! log_mem_size: 512 [01-25 00:33:48][1][527]extend_start_cb [01-25 00:33:48][1][527]extend_start_cb [01-25 00:33:48][1][527]extend_start_cb [01-25 00:33:48][1][527]extend_start_cb [01-25 00:33:48][1][527]extend_start_cb [01-25 00:33:48][1][527]extend_start_cb [01-25 00:33:48][1][527]extend_start_cb [01-25 00:33:48][1][527]extend_start_cb [01-25 00:33:48][1][527]extend_start_cb [01-25 00:33:48][1][527]extend_start_cb [01-25 00:33:48][1][527]extend_start_cb [01-25 00:33:48][1][527]extend_start_cb [01-25 00:33:48][1][527]extend_start_cb log file num 1 file_size 0 [01-25 00:33:48][1][525]dclog init set server and port server=devlog.ys7.com port=80 tttttchan=2vaddr=0xb4477000 file[init/dvr.c]func[setSubStreamRecStatus]line[2003] iChan:[2]iRec:[0]iSubRec:[0] file[init/dvr.c]func[setSubStreamRecStatus]line[2004] iChan:[2]szRecCount:[1]szSubRecCount:[0] [01-25 00:33:48][1][525]dclog register item 0 get item opt error callback func is NULL [01-25 00:33:48][1][525]dclog set item opt type=1004 enable=0 interval=60 [01-25 00:33:48][1][525]dclog register item 1004 success index=0 enable=0 interval=60 [01-25 00:33:48][1][525]dclog vtdu init success [01-25 00:33:48][1][530]dclog thread start success [01-25 00:33:48][1][530]dclog check report type 1004 is registered but disabled START SMD!!!!!!!!!! <DSP>vca 11QueVcaChan vcaChan:0realChan:0 <DSP>vca DspVcaSmdQueChan smdChan:0vcaChan:0 <DSP>vca 1HostSMDStart 704 576 pSmdCtrl->analyseParam.VcaWidth = 176 pSmdCtrl->analyseParam.VcaHeight = 144 <DSP>vca SMD_Open okvcaW:176vcaH:144 <DSP>vca dst 7 9 2 <DSP>vca fun:DspVcaSetDataFrameRate src:30dst:12 <DSP>vca chan 0 HostStartSmd success <DSP>vca chan 0 set SMD rule successa <DSP>vca rule_num:0 START SMD!!!!!!!!!! <DSP>vca 11QueVcaChan vcaChan:1realChan:1 <DSP>vca DspVcaSmdQueChan smdChan:1vcaChan:1 <DSP>vca 1HostSMDStart 704 576 pSmdCtrl->analyseParam.VcaWidth = 176 pSmdCtrl->analyseParam.VcaHeight = 144 <DSP>vca SMD_Open okvcaW:176vcaH:144 <DSP>vca dst 7 10 2 <DSP>vca fun:DspVcaSetDataFrameRate src:30dst:12 <DSP>vca chan 1 HostStartSmd success @@@@do not need poc test@@@@ !!!!!!!!!!!!!!!sc_hicore is start ok!!!!!!!!!!!!!!!! <DSP>vca chan 1 set SMD rule successa <DSP>vca rule_num:2 <DSP>vca ID:1 TYPE:0 event_type:1 <DSP>vca x:0.699000 y:0.590000 <DSP>vca x:0.456000 y:0.560000 <DSP>vca ID:2 TYPE:0 event_type:1 viLostProc:Chan 1 VI lost. viLostProc:Chan 2 VI lost. file:smd/smd_proc.cline:2256 smdCtrlTask:set chan smd failed. file:smd/smd_proc.cline:2256 smdCtrlTask:set chan smd failed. file:smd/smd_proc.cline:2256 smdCtrlTask:set chan smd failed. file:smd/smd_proc.cline:2256 smdCtrlTask:set chan smd failed. file:smd/smd_proc.cline:2256 smdCtrlTask:set chan smd failed. [01-25 00:33:49][1][549]RLIMIT getrlimit rlim_cur = 16384 max = 163840 [01-25 00:33:49][1][549]RLIMIT X fd rlim_cur = 16384 max = 163840 read_rs485: recv data 1 0 @@@@do not need poc test@@@@ Device Is Ready $$$$$$$$$$$$$ iAoChans[4] $$$$$$$$$$$$$ g_aoChan[0]=[2] 1+0 records in 1+0 records out 65536 bytes (64.0KB) copied 0.005197 seconds 12.0MB/s [ERROR]:savelog.c[1140] iCurrTime[1548376432] iTempTime[1548376148] [ERROR]:savelog.c[1326] flash can not be Operate and quit! Share this post Link to post Share on other sites
LuisVeloso 0 Posted March 30, 2021 Dear friends, Could someone help me with a firmware for DS-7208HVI-ST? Can't find it anywhere. Thanks in advance. Share this post Link to post Share on other sites
tomcctv 190 Posted March 30, 2021 49 minutes ago, LuisVeloso said: Dear friends, Could someone help me with a firmware for DS-7208HVI-ST? Can't find it anywhere. Thanks in advance. Hi. There is none Over 11 years old why are you looking for firmware Share this post Link to post Share on other sites
LuisVeloso 0 Posted March 31, 2021 16 hours ago, tomcctv said: Hi. There is none Over 11 years old why are you looking for firmware Hello. It's to a client. Anyone have it on a old HDD? Share this post Link to post Share on other sites
tomcctv 190 Posted March 31, 2021 49 minutes ago, LuisVeloso said: Hello. It's to a client. Anyone have it on a old HDD? So your looking for system software not firmware? it’s an old cif recorder .... pointless Share this post Link to post Share on other sites
teoro 0 Posted October 8, 2021 Need hikvision ds-7204hqhi-k1 firmwere Thank you Share this post Link to post Share on other sites
