dahua hdw3200sp pinout problem

[Cemmac 0]

Hi



I have a situation with my Dahua IP camera, wich was cable cut off. Original Dahua RJ45 connector was lost, so i have to add other one. Problem is wiring of colours as i haven't got previous connector. in storage I have 1 identical camera also with non-original connector on, wich someone connect it before time (this one works fine).Cameras are connected to POE working switch. As i discover from working camera are correct pins like this:



1.brown

2.purple

3.orange

4.blue

5.blue

6.yellow

7.grey

8.grey



But it's not working at this stage on this one. It's not even turn on red smd leds on start, so basicly no power. As my boss provocate me, that color lines could be mixed and it's not rule that Dahua always use the same pinout for same model of camera...stupid.. So i try to replace like this:



4.yellow

5.yellow

6.blue



Now smd leds go on, but no connection to pc video...As i know some of these 3 pins(i think 6.) is TX+ communication, wich technically lead to cpu of camera...Am I fry everything?





Regards!

[tng5737 0]

see this:

viewtopic.php?f=19&t=39296&p=262540#p262540
