telnet missing

[n95k 0]

Hi All, I am new and great info here



I have a XM board based DVR which had telnet access, send detect email was having problems and I upgraded the box with newer firmware. Now the telnet access is gone and the port is not available anymore.



FW version was "AHB7004T-EL_V4.02.R11.3070.Nat.OnvifC.20160524.bin"



I can unpack modify and pack the bin files, so what should I do to the FW to get telnet back?



Appreciate the experts advise.



/etc/init.d/rcS is like below;



#!/bin/sh



/etc/init.d/dnode

echo /sbin/mdev > /proc/sys/kernel/hotplug

mdev -s



mount -t squashfs /dev/mtdblock2 /usr

mount -t squashfs /dev/mtdblock3 /mnt/web

mount -t squashfs /dev/mtdblock4 /mnt/custom

mount -t cramfs /dev/mtdblock5 /mnt/logo

mount -t jffs2 /dev/mtdblock6 /mnt/mtd



mount -t ramfs /dev/mem /var

mount -t usbfs none /proc/bus/usb/



mkdir -p /mnt/mtd/Config /mnt/mtd/Log /mnt/mtd/Config/ppp /mnt/mtd/Config/Json



if [ ! -f /mnt/mtd/Config/HvrMode ] && [ -f /mnt/custom/HvrMode ]; then

cp /mnt/custom/HvrMode /mnt/mtd/Config/

fi

if [ -f /mnt/mtd/Config/ppp/3gdigal ]; then

chmod 777 /mnt/mtd/Config/ppp/3gdigal

fi

cd /usr/etc

./loadmod

ifconfig eth2 up

ifconfig eth2 192.168.1.12

echo 2548 > /proc/sys/vm/min_free_kbytes

routedaemon&

dogtest &



#BurnSataHub &



telnetd &



timecheck &



macGuarder &



sleep 3

netinit &

sleep 1



/usr/etc/pppd pty /etc/ppp/pppoe-start file /etc/ppp/pppoe-options &



/mnt/custom/extapp.sh &



#unrar x /usr/bin/Sofia.rar /var/

cp /usr/bin/Sofia.tar.lzma /var/

cd /var/

tar -axf /usr/bin/Sofia.tar.lzma



chmod 777 /var/Sofia

rm /var/Sofia.tar.lzma -fr

dvrHelper /lib/modules /var/Sofia 127.0.0.1 9578 1

[n95k 0]

figured it out, very easy. all ok now. how do i close this thread?

[rotra 0]

Hi!

I have the same your problem with the emails. Where did you found the new firmware?

Thank you

[d94705 0]

Am wondering what you did that was easy to fix this. I'm having the same problem. No telnet.

Thanks.

[eduardoAvelar 0]

Hi @n95k. I'm facing the same issue with the DVR that I'm working on. The manufacture is the same as yours.

The steps are below:

$ sudo unzip General_General_AHB8004R-MH_V4.03.R11.7601.Nat.OnvifC.20190926.bin
Archive:  General_General_AHB8004R-MH_V4.03.R11.7601.Nat.OnvifC.20190926.bin
  inflating: custom-x.cramfs.img
  inflating: InstallDesc
  inflating: logo-x.cramfs.img
  inflating: romfs-x.cramfs.img
  inflating: u-boot.bin.img
  inflating: user-x.cramfs.img
  inflating: web-x.cramfs.img

$ file romfs-x.cramfs.img
romfs-x.cramfs.img: u-boot legacy uImage, linux, Linux/ARM, OS Kernel Image (gzip), 3481600 bytes, Thu Sep 26 03:12:37 2019, Load Address: 0x00050000, Entry Point: 0x00430000, Header CRC: 0x050D9A23, Data CRC: 0x0525E509

$ dd bs=1 skip=64 if=romfs-x.cramfs.img of=romfs-x.cramfs
3481600+0 records in
3481600+0 records out
3481600 bytes (3,5 MB, 3,3 MiB) copied, 405,923 s, 8,6 kB/s

$ file romfs-x.cramfs
romfs-x.cramfs: Squashfs filesystem, little endian, version 4.0, 3481434 bytes, 217 inodes, blocksize: 262144 bytes, created: Thu Sep 26 03:12:37 2019

$ sudo unsquashfs romfs-x.cramfs
Parallel unsquashfs: Using 4 processors
184 inodes (197 blocks) to write
created 50 files
created 33 directories
created 0 symlinks
created 0 devices
created 0 fifos

The result was:
squashfs-root/

Inside the squashfs-root/, we have:
total 16
drwxrwx--- 1 root vboxsf 4096 set 26  2019 ./
drwxrwx--- 1 root vboxsf 4096 dez 16 17:32 ../
drwxrwx--- 1 root vboxsf    0 set 26  2019 bin/
drwxrwx--- 1 root vboxsf    0 set 26  2019 boot/
drwxrwx--- 1 root vboxsf    0 abr 24  2010 dev/
drwxrwx--- 1 root vboxsf 4096 fev  7  2018 etc/
drwxrwx--- 1 root vboxsf    0 abr 20  2010 home/
drwxrwx--- 1 root vboxsf 4096 set 26  2019 lib/
drwxrwx--- 1 root vboxsf    0 abr 20  2010 mnt/
drwxrwx--- 1 root vboxsf    0 abr 20  2010 opt/
drwxrwx--- 1 root vboxsf    0 abr 20  2010 proc/
drwxrwx--- 1 root vboxsf    0 abr 20  2010 root/
drwxrwx--- 1 root vboxsf    0 set 26  2019 sbin/
drwxrwx--- 1 root vboxsf    0 abr 20  2010 share/
drwxrwx--- 1 root vboxsf    0 abr 20  2010 slv/
drwxrwx--- 1 root vboxsf    0 abr 20  2010 sys/
drwxrwx--- 1 root vboxsf    0 abr 20  2010 usr/
drwxrwx--- 1 root vboxsf    0 abr 20  2010 var/

After edit the /etc/init.d, I made the squashfs:

$ mksquashfs squashfs-root/ custom-x.cramfs

If I compare the romfs-x.cramfs before edit and after, I can see the diference on inodes number:

--> Before unsquashfs and edit:
$ file romfs-x.cramfs
romfs-x.cramfs: Squashfs filesystem, little endian, version 4.0, 3481434 bytes, 217 inodes, blocksize: 262144 bytes, created: Thu Sep 26 03:12:37 2019

--> After the squashfs and edit
$ file romfs-x.cramfs
romfs-x.cramfs: Squashfs filesystem, little endian, version 4.0, 3833358 bytes, 83 inodes, blocksize: 131072 bytes, created: Thu Dec 17 01:14:53 2020

Then i made the image whit edited romfs:

$  mkimage -A arm -O linux -T kernel -n "linux" -e 0x00430000 -a 0x00050000 -d romfs-x.cramfs romfs-x.cramfs.img
Image Name:   linux
Created:      Wed Dec 16 17:30:40 2020
Image Type:   ARM Linux Kernel Image (gzip compressed)
Data Size:    3833856 Bytes = 3744.00 KiB = 3.66 MiB
Load Address: 00050000
Entry Point:  00430000

After upload the DVR by TFTP and u-boot command, the download was executed perfectly.

But, after the reset, the process stops and an infinite loop with u-boot start and fail became my actual situation.

It can be solved if I reload the original romfs-x.cramfs.img file.

What am I doing wrong in the image repack process?

Thanks in advance.
