Angus19

2 IP cameras over 1 cat 5 cable

Recommended Posts

Hi

I have been told you can run 2 cameras over one CAT cable ?

i have H265 plus hikvision cameras  and would like to add more but restricted on cabling

Can anyone tell me if this is possible please?

many thanks

Share this post


Link to post
Share on other sites

I have 2 on separate cat 5 cables and want to add another one to each cable if possible- nvr has available ports

i tried a splitter adaptor off eBay to no avail



many thanks

Share this post


Link to post
Share on other sites

Hi problem with using a splitter is no power

you have two options …. Use a 4 way switch with Poe …. But you will need to call cameras back to nvr from your router

but quickest way is buying two tp-link Ethernet over power adapters 1 at camera end and one nvr end …… no cable needed

I use these all the time with no problems it is also the cheapest way

https://www.tp-link.com/uk/home-networking/powerline/tl-pa717-kit/



Share this post


Link to post
Share on other sites

Many thanks for your reply

i clicked on the link - that seems to be for extending your WiFi via the electrics or I am not understanding how that then allows me to operate 2 cameras via the one cat 5 cable?

apologies- a bit of a thick mick at this end!

Would appreciate further feed back

cheers





Share this post


Link to post
Share on other sites

IEEE 802.3af and 802.3at only use two of the four pairs.  As long as your camera uses one of these PoE/PoE+ standards, you should be able to use one of these splitters.  One splitter has a female RJ-45 which connects to your second camera through a patch cable.  The figure on Amazon has it backwards- while it would work, who has two cameras really close to each other.
